Load bearing floors for domestic and commercial applications

The load bearing capacity of a floor or roof is key to its successful application within the building and ensures that it is up to the task it is being asked to do.

This ranges from relatively the simple and small domestic loads associated with houses and apartments through to commercial application from offices through to schools and hospitals and even car park roofs.

We have a variety of solutions that will meet the demands of your project and we are often able to reduce weights and depths of these systems to have an overall positive effect on the building design and function.

Our load bearing systems include those listed below, these can be used for the following applications amongst others:

  • Domestic floors
  • Commercial floors
  • Balconies and Terraces
  • Garages and Car Parks
  • New Build and Renovation

Available Systems

Lewis Deck

Lewis Metal Dovetailed Sheeting Deck with acoustic Sylomer resilient strips

LEWIS Dovetailed metal decking, as part of a joisted floor system, provides a first class solution where acoustics and fire protection are key concerns. The Lewis system works very well with screeded underfloor heating and cooling systems, allowing them to work more efficiently than without the sheets in place. LEWIS provides a number of solutions …

Read More

Op-Deck

Op-deck is a lightweight insulated floor and roof system. The advantages of composite metal deck concrete floors and traditional rib floors have been combined in this unique patented floor/ roof system. This insulated concrete floor/ roof system (ICF) is based on traditional concrete installation but with optimal design and installation flexibility. It is suited to …

Read More

Max 4

Max4 without UFH

Max4 reinforcing sheets provide a great solution for leveling uneven existing floors with the introduction of reinforced ultra thin light weight liquid screed floors in projects where weights and height restrictions are an issue. The Max4 reinforcing sheets are manufactured from 2 sheets of special profiles steel and designed for use on existing timber or …

Read More

Hody

Hody profiled steel sheets have a modified trapezium shaped profile of 60 mm in height and intended for constructing, so-called, ‘low’ composite steel decking. The finished concrete floor is between 110 mm – 290 mm high and Hody trapezium sheets can be used on free spans of up to 8 metres over the bearing construction. …

Read More

FastSlab Foundation

FastSlab foundation system

The FastSlab Foundation System is a fast track method to construct foundations and ground floors, ideal for sites with limited access, poor ground conditions, flood plain locations and areas with tree root issues. It also works equally well in all ground conditions whilst eliminating a sometimes difficult and expensive muck shift. A typical FastSlab house …

Read More

FastSlab

The FastSlab Ground Floor system is designed to make it quick and easy to replace existing suspended ground floors with an insulated concrete or screeded floor. This gives the solid feel of a concrete ground floor with the benefit of maintaining the ventilated void beneath to prevent moisture issues in the existing walls. The FastSlab …

Read More

Lewis SteelFrame Concrete Floor (SCF) system

Lewis Steel Concrete Floor System

The LEWIS® Steel Frame Concrete Floor (SCF) is a patented self-supporting floor system. The floor system features prefabricated elements consisting of a closed steel frame of cold formed C-sections that have been cast into a reinforced concrete shell, this concrete shell also forms the ceiling slab for the floor system. The steel frame features round …

Read More

FAQs22

Ask CDI a Question

  • Q

    What are the Lewis Deck sheet sizes?

    A

    Q: What sheet sizes are held in stock for delivery within a few days after order? A: We stock 2500mm and 1300mm sheets.  These are all 630mm wide and 16mm deep.  Deliveries are made via the pallet network directly to site.  The smaller sheets are aimed at small bathroom renovation projects and can be supplied in small numbers via TNT. 2.5* and 1.3m sheets allow for the 100mm overlap to occur over a joist, with joist centres being either 300mm, 400mm, 600mm, 800mm*, 1200mm and 2400mm*. (*2.5m sheet only) For larger projects we are able to produce bespoke sheet sizes if required, please get in contact to discuss other options for sheet sizes.

    Q

    Lacomet – How come it has no scrap value?

    A

    Lacomet – How come it has no scrap value? Many of the projects that we get involved in starts with a phone call or email to us from someone researching replacing stolen leadwork. Many of these are old buildings, such as schools or churches, where this isn’t the first time that the lead has been stolen and they call us fed up with having to replace it again full in the knowledge that they will more than likely go through the same problem once more in the near future if they continue to use lead. One of the big benefits that Lacomet FL brings to a project is the fact that it has no scrap value and therefore the chances of it being stolen are massively reduced. Due to the 2 thin aluminium layers, and its five layer total construction, it is of no value to thieves. Lacomet can be recycled but the polyester based coating would need to be de-laminated first and the amount of recovered aluminum is then very low, in fact it would be easier and more profitable to collect empty drinks cans than to mess about stripping Lacomet down. We can also supply stickers that can be placed in strategic locations informing people that what is now on the roof is not lead and that it has no scrap value.

  • Q

    Why don't my Lewis sheets interlock like they do in the video?

    A

    Q: Why don't my sheets interlock like they do in the video? A: The sheets have two sides (one printed, one plain), the dovetails on either side are different widths, it is then necessary to alternate the sheets print up and then print down.

    Q

    Is this a question?

    A

    If it is, this is an answer.
